Description

Features:

8 x 720p/1080p videochannels
GPS + BDS dual positioningmodules
WiFi-AP 3G/4G LTEtelecommunication
CAN bus connection ( ignition, speed, brake, lights,motor rotations, fuel consumption, etc. )
Dual SIM cardslots
With an optional external rugged data memory devicethat survives 1100⁰C high temperature fire and functions 100m underwater for 240 hours
For fleet tracking, monitoring and management onlinewhen connected to our platform, better performance and more functions if with our ADAS system
Recommended for passenger buses, heavy duty trucks,oil tankers and other commercial
Size：200 x 200 x70mm
NWT：2000g

System	Linux 3.10
Video Input	8 CH AHD720P/1080P + 1 CH IPC
Video Output	2 CH CVBS
Audio	8 CH input 2 CH output
Display	PAL: 704 x 576 NTSC: 704 x 480
Video Compression	H.264
Audio Compression	G.726
Playback	single channel 1/4/8 channels with app.
Storage	SD2.0 x 1 ( max 512G ) HDD x 2 ( 4TB ) flash memory: 1G SLC Nandflash
Localization	GPS + BD2 dual modules
Wireless Communication	3G/4G, WiFi
Interface	VOIP USB2.0 x 2 SIM/UIM x 1 LAN 10M/100M/1000M RS485 x 2 RS232 x 2 CAN port x 2
Power	Input: DC8V～36V output: 12V@1A, 5V@1A
Temperature Range	-30～70℃ ( operation )
*Parameters of the optional crashworthy fireproof memory device*
Fire Resistance	1100℃/15min 950℃/20min 260℃/120min
Water Immersion	100m underwater 240 hours
Impact Force	50g 100ms ( all axes )

Features	4G, GPS, 4G, GPS, WiFi, BT, 4G, GPS, WiFi, Face Identification, Driver Monitoring System/DMS
