Doorbell Camera : IP007G

SKU: E-0255

$41.10

Download Catalog

  • Description
  • Additional information

Description

Specifications:

Main Chip Hi3518EV200
Sensor 1/4” CMOS OV9732 Sensor
Operating System Lite OS
Mobile system Ubell,ios10.0,android5.0 and above
Number of users online Multiple users are online simultaneously (4 people simultaneous)
Dynamic DNS Bring your own dynamic domain name
Processor Hisilicon processor with built-in ARM926@max. 440MHz and high-speed video coprocessor
Describe Features Wireless connection, Ultra-low power consumption, Remote active awake, Quick push(2-3 sec.)
Use A video call from visitors via pressing the doorbell button, Hoster will get the call.
Waking up Methods Button, PIR detection, Smartphone
Alarm Push 1 Second
Collect CCD CCD 1/4” CMOS OV9732 Sensor
Sensor performance Support automatic white balance, automatic gain control, backlight compensation
SNR ≧39db
LUX 0.8Lux/F1.4(Color pattern), 0.3Lux/F1.4(Black and white pattern)
Lens/Visual angle 1.77mm@F2.4/166°
LED Double filter automatic switching, six 850-nm 28mil high power infrared lamp, night vision 8 meters
IR Distance Effective distance 3-5M
IR Control IR opens night vision, automatic detection of infrared and ICR; IR shuts the night vision function off the infrared and the ICR is fixed in daily viewing mode
Audio Input built-in 48db microphone
Output Built-in speaker( 8 Ω 1w)
Interphone Two-way voice talk, bring back the echo cancellation
Compression standard/code rate ADPCM/32kbps
Video Compression standard H.264 main profile/H.264 baseline profile
Video Coding 720p/15fps | 1080p/24fps
Resolution 1280*720 | 1920*1080
Video mode PIR detection video, doorbell button trigger video, manual video
Storage The TF card stores the maximum support for 32gb
Network Network protocol TCP/IP,HTTP,TCP,UDP,SMTP,DHCP,DNS,P2P
Wireless network 802.11b/g/n
Wireless network security WPS security encryption
Wireless connection One-Button WIFI configuration+Voice Wave Match
Other Power Battery power-two 18650 batteries, USB 5V power supply (Standby time-5-6 months by 2pcs batteries)
Standby time about 6 months(10 times wake up, 15s/time)
Power consumption Standby current 120μA, working current 170mA
Work environment Working temperature: -10℃-50℃, Humidity ≤95%
Installation Wall mounting
Cloud storage Optional 7 day cycle permanent free cloud storage
Material ABS
Water-proof level /
Product size Length 96.5mm x diameter 65.5mm
Product weight 0.32kg/No battery
Package size 100mm x 175mm x 77.5mm



Additional information

Resolution

1080p
